NX CAM MANUFACTURING SOFTWARE
Digitalize part manufacturing With Siemens NX CAM
Cut machining time by 60 percent with NX CAM software
New advanced capabilities in NX CAM from Siemens for mold and die machining, production machining and complex parts machining let companies achieve a new level of efficiency by digitalizing the part manufacturing process.
Advanced capabilities in NX CAM for mold and die machining, production machining and complex parts machining provide powerful advantages. Adaptive Milling is a new high-speed cutting strategy that reduces machining cycles by up to 60 percent. And, a new Tube Milling operation drastically simplifies NX CAM 5-axis programming of complex features, including ports of engine blocks and shrouded blisks.
MOLD AND DIE MACHINING IN NX CAM SOFTWARE
Adaptive milling is a new high-speed cutting strategy that can reduce machining cycle time by up to 60 percent. This intelligent roughing method enables deep cuts and constant tool load that increases material removal rate, while extending tool life. Smooth finishing tool paths with consistent step-overs across the entire machined area ensures high-quality machined surfaces.
NX CAM PRODUCTION MACHINING
For high-volume production of complicated parts with many features, the new NX Machining Line Planner combined with integrated NX CAM enables distribution, balancing, programming and simulation of operations over multiple setups and machines. By using a digital twin of complete machining lines to optimize the process, automotive and machinery manufacturers can reduce planning time and increase throughput.
COMPLEX PARTS MACHINING IN NX CAM
New Tube Milling 5-axis capabilities drastically simplify programming of complex features, including ports of engine blocks and shrouded blisks for turbo machinery. These efficient and safe toolpaths for roughing and finishing ensure high-speed and error-free 5-axis machining. And, the expanded robotics machining capabilities in NX CAM let you program pick-and-place operations, such as machine tending and tool loading operations.
NX CAM ADDITIVE MANUFACTURING
Industrialize additive manufacturing with NX
New capabilities in NX CAM for additive manufacturing make it easier than ever before to print production-quality parts with the full traceability of an unbroken data thread.
Additive manufacturing capabilities in NX CAM include robust capabilities for industrial production of 3D printed parts, all within the NX environment. Engineers can quickly set up build trays, automatically nest parts, design support structures, and create machine-specific output to drive industrial printers, including powder bed and HP Multi Jet Fusion printers.
POWDER BED PRINTING
Powder bed printers remain the most popular option for printing of metal parts. NX CAM now has a robust, integrated connection with these printers–powered by Materialize. This includes support structure creation, build tray setup, and a build processor framework for connection to powder bed machines.
HP MULTI JET FUSION PRINTERS
NX CAM has a new module (powered by Materialize) enabling customers to design, optimize, simulate, prepare print jobs, and inspect processes for HP Multi Jet Fusion 3D printers. NX users can load multiple models, auto nest, and submit the job to HP 3D printers in a single NX environment and with a minimum number of steps.
DESIGN FOR ADDITIVE MANUFACTURING
Companies are looking to innovative solutions in the constant drive to reduce component weight and improve resource usage. Lattice structures are one way designers can meet these goals without compromising on strength and structural integrity. In NX, integrated lattice structures, combined with Convergent Modeling Technology™, makes creating cutting-edge structures like these easier than ever before.
NX TOOLING DESIGN CAM SOFTWARE
Increase profitability using automated NX tool costing
Tooling manufacturers can now automatically and accurately determine tooling production costs using the new integrated capabilities of Siemens PLM Software’s solutions. The digitalized process, from 3D part model to detailed cost estimate, can replace the time-consuming manual job tasks to improve your estimates’ accuracy. This gives tool manufacturers a unique advantage in this highly-competitive industry.
NX FEATURE2COST
You can automatically identify features on molded or stamped parts using NX Feature2Cost. The robust feature recognition capability analyzes 3D part model, recognizes and classifies many types of part features, such as undercuts, ribs and bends. Although fully automated, the software also gives you flexibility to apply your expertise in the process. This can further improve accuracy of the estimated costs.
TEAMCENTER PRODUCT COST MANAGEMENT
The complete set of recognized features, along with their parameters can be seamlessly transferred to the integrated Teamcenter Product Cost Management software. After providing additional information about material type and machines, the system can precisely calculate the tooling cost. By being able to quickly provide accurate quotations, tooling manufacturers are positioned to win more orders and maximize their profitability.
NX CAM 3AXIS MILLING
A Comprehensive NX CAM 3-Axis Milling Software Solution
Siemens NX CAM 3-axis milling software module in NX provides a comprehensive solution for the programming of free form parts, such as molds and dies.
With Siemens NX CAM 3-axis milling software you can achieve a high material removal rate and superior surface finish. The advanced cutting strategies include roughing, rest milling, high-speed machining (HSM) and finishing.
SMOOTH OFFSET CUTTING
NX provides smooth offset pattern cuts with special step over moves and corner treatments to maintain high feed rates and fine finishes. You can cut inside out or outside in.
SMOOTH TRANSITIONS
Step over and traverse motions are smoothed to minimize machine jerk and keep feed rates maximized throughout the entire operation.
ROUGHING
The optimized roughing methods in NX maximize the material removal rate without overloading the tool. It features:
Automatic multiple cut ranges with variable cut depths
HSM cutting patterns for increased material removal rate
In-process work piece (IPW) automatically tracks the machined and remaining material
TROCHOIDAL CUTTING STRATEGY
The trochoidal cutting method is a high-speed roughing method that maintains high metal removal rates while managing tool loads. It automatically prevents you from exceeding your specified cutting conditions.
The smooth corners, step overs, and engagements of this cutting strategy ensure safe cutting conditions at high speeds and feeds.
REST MILLING
Fully automated rest milling removes uncut material from previous operations and eliminates air-cutting. With the rest milling capabilities you can:
Generate efficient multi -stage roughing based on IPW
Achieve consistent stock for the next cutting operation
Use cutting parameters fine-tuned for HSM
FINISHING
NX CAM 3-axis milling offers a wide range of finishing techniques that deliver superior surface finish quality. The smooth and continuous cutting patterns, such as Z-level and offset, can produce consistent surface finish in both steep and shallow areas of the part.
STREAMLINE TOOL PATH
This HSM operation produces smooth, flowing patterns with fine finishes at high feed rates independent of surface geometry construction methods. It provides equally spaced passes in both steep and shallow areas, and follows the natural shape of the machined area for a superior finish.
CORNER FINISHING
The flow cut cutting strategy enables you to semi-finish and finish uncut areas in a single operation. NX CAM automatically identifies the un -machined areas in corners and creates an efficient tool path. NX can also automatically generate different flow cut cutting patterns for steep and shallow areas to improve machining conditions.
SYNCHRONIZED POINT DISTRIBUTION
With Siemens NX CAM, you can ensure that data points on adjacent finish passes of the tool are properly aligned with synchronized point distribution. The consistent machine motion across the passes delivers superior surface finish compared to traditional cutting methods.
FEED RATE OPTIMIZATION
NX CAM Software can automatically analyze the cutting tool’s material removal rate and adjust feed rate to achieve uniform material removal rate.
The optimized federate can improve machining productivity and extend the tool life.
SAFE CUTTING STRATEGIES
Automatic collision detection for tools and holders ensures safe machining for even the most demanding part geometry.
NX CAM not only considers the part model geometry during the tool path creation, but it also takes into account the IPW. You can also select the optimum tools for your job by using NX’s capability to report minimum tool length based on the part geometry.
NX CAM 5-AXIS MILLING
New advanced capabilities in NX CAM 12 5-Axis Milling for mold and die machining, production machining and complex parts machining provide powerful advantages to part manufacturers. We at DDS look forward to help you benefit from these new commands. Contact us for demo/ support/training anywhere in Gurgaon, Noida, Faridabad, Delhi and around.
MILLING SOFTWARE FOR PRECISE, EFFICIENT MACHINING OF COMPLEX PARTS
The siemens NX CAM 5-axis milling software module in NX enables you to machine complex parts with fewer operations and setups – reducing cost and delivery times.
With NX CAM 5-axis milling, you can create precisely controlled tool paths on complex surfaces with effective collision and gouge checking.
Z-LEVEL WITH TILTED TOOLS
You can use shorter tools to machine deep areas with NX CAM 5-axis Z-level cutting. When necessary, NX automatically tilts the tool axis to prevent collisions with the tool holder. The reduced tool deflection results in reduced tool wear and better surface finish.
NX CAM 5-AXIS STREAMLINE
The smooth-flowing streamline strategy is an ideal cutting method for 5-axis high-speed machining (HSM). The flexible cut pattern can handle any surface geometry, regardless of construction methods. The streamline tool path follows the natural shape of the machined area for superior finish.
CONTOUR PROFILING
The variable-axis contour profiling automates the programming of machining features with complex drafted walls. You can quickly select the floor geometry, and then NX will recognize the drafted walls and generate the 5-axis tool path.
SWARF CUTTING
With the swarf cutting, you can keep the side of the tool aligned with the machined faces. NX also allows you to control the tilt of the cutting tool. This strategy improves the surface finish and reduces machining time.
3- TO 5-AXIS TOOL PATH CONVERSION
You can significantly improve productivity of mold and die machining by using multi-axis cutting. With the automatic tool-tilting in NX, you can efficiently machine molds and dies with deep cavities.
NX analyzes the tool path and automatically tilts the tool to avoid holder collisions. This 5-axis milling method enables you to use shorter tools to reduce vibration and tool deflection.
HIGH LEVELS OF USER CONTROL
NX CAM 5-axis milling software includes high levels of user-controlled multi-axis machining. You can control 5-axis tool motion with traditional drive, part and check surface specifications. These flexible options enable you to program virtually any complex part model.
MACHINE TOOL SIMULATION
The machine tool simulation in NX provides you with the essential tools for proving out 5-axis machine motion. The motion of the machine tool simulation is based on the NC output of the NX post processor. As the G-codes are processed, a 3D model of the machine – with the part, fixtures and tooling – moves in the way the real machine tool will move.
NX CAM PRODUCTION MACHINING
NX CAM Production Machining Cut programming time by 60 percent with NX CAM software
NX provides complete computer-aided manufacturing (CAM) software solutions for machine tool programming, postprocessing and machining simulation. NX CAM software’s advanced functions in each of its modules can maximize returns on your investments in the latest machine tool technology.
ADVANCED PROGRAMMING CAPABILITIES
NX CAM software provides a wide range of functionality, from simple NC programming to high-speed and multi-axis machining, enabling you to address many tasks with one system. The flexibility of NX CAM software means that you can easily complete the most demanding jobs.
Powerful industry-specific CAM software capabilities for mold and die machining, production machining, complex parts machining, and shop floor connectivity, have been specially-designed to dramatically increase your overall manufacturing productivity in NX CAM.
With the help of Siemens PLM NX CAM Production Machining Software. You can automate the programming of prismatic features and, more importantly, minimize the cycle time on the machine tool with NX. Hole-making is a significant focus for production manufacturers, because holes make up a large part of this type of machining. NX CAM provides several efficiency improvements and more automation for hole- making, including new optimized operations for deep-hole and sequential drilling. These new methods yield reduced cycle times and 60 percent faster programming.
